Description
Mi-Glow® 800L is a pre-proportioned combination of Mi-Glow® 800 fluorescent yellow-green particles and CircleSol M™
Mi-Glow® 800L uses or latest generation Mi Glow® 800 particles which have exceptional sensitivity, uniform size, and ideal magnetic characteristics for fluorescent magnetic particle inspection. Mi-Glow® 800L is a fluorescent yellow/green powder premixed with our petroleum carrier fluid CircleSol M packaged in a convenient 5 gallon container at a certified concentration of .2mL. CircleSol M ensures excellent particle mobility and surface coverage to allow for a reliable magnetic particle inspection. Mi Glow® 800L is designed to be used with UV-A light to detect discontinuities typically found in the NDT of forgings, castings, welds, and piping.
It is designed to be used with black light to detect very fine discontinuities in finished products.
Advantages
-
- High flashpoint & low odor helps reduce safety concerns
- Meets all – relevant industry standards
- Economical
- Circle Systems unique bonding method offers a very tightly bonded particle which
Provides total particle encapsulation, eliminating free unbonded pigment, resulting in a low background, high performing magnetic particle inspection powder
Sensitivity – The superior Mi Glow 800 particles have larger surface areas which mean smaller sized particles with increased sensitivity and brightness
Item # / Package Size
#3143 – 5 gallons/pail
Technical Specifications
Physical Characteristics
Forest green liquid, odorless.
Particle Certification
Particles, carrier and mixture conform to or exceed all applicable industry specifications, including but not limited to MIL-STD-1949, MIL-STD-271(SH), ASTM E 709, ASTM B & PV Code – Section V and NAVSEA 250-1500-1. AMS 3044, AMS 3045, AMS 3161, AMS 2641 and DOD-F-87935 are covered under MIL-STD-1949.
Particle Color: Fluorescent Yellow-Green
Average Particle Size: 3 µm
AMS Standard: 3045
SAE Sensitivity*: 8
Temperature Range: 32-120°F (0-49°C)
*Representative of the number of lines shown on an AISI 01 Ketos tool steel ring as defined in SAE AS5282.
