Compact and portable, the CleanTech Commercial Finishing Laser 1010 is our entry-level handheld finishing laser system. This next-gen model features mobile connectivity, overheat protection, and a smaller scanhead – it also utilizes dual axis technology which allows it to effectively process complex surfaces. The CleanTech CF-1010 is an ideal solution for small-scale applications, used for polishing, cleaning, and top-layer coating removal on a wide range of materials.
The CleanTech CF-1010 presents professionals with a non-abrasive, safe, and sustainable surface treatment tool. Whether you’re restoring auto parts, removing residue from molds, or trying to achieve a fine polished finish, this hand held laser cleaning machine will save you time and money while helping you revamp your operating processes.
Applications for CTCF-1010
| Surface Conditioning |
Degreasing |
| Corrosion Removal |
Surface Preparation |
| Decontamination |
Surface Texturing |
| Coating Removal |
Injection Mold Cleaning |
| Pre-Adhesion Treatment |
Oxide Removal |
| Pre-Weld Preparation |
Anodization Removal |
| Post-Weld Treatment |
Materials That the CTCF-1010 Can Be Used With
| Aluminum |
Composites |
| CFRP |
Nickel |
| Steel |
Concrete |
| Silicone |
Chrome |
| Copper |
Ceramics |
| Plastics |
Cast Iron |
| Brass |
Marble |
| Thermoplastics |
Carbide |
| Titanium |
& More |
Technical Specifications for CTCF-1010
| Model |
CTCF-1010 |
| Strip Rate Per Hour |
Up to 6 ft² |
| Laser Type |
Fiber |
| Scanner |
Dual Axis |
| Operation Mode |
Pulsed |
| Wavelength |
1064 nm |
| Head Cable Length |
9.8 – 30 ft (3 – 9 m) |
| Head Weight |
3.5 lbs |
| Size W x H x D |
22 x 44 x 18 in (559 x 1118 x 457 mm) |
| Unit Weight |
114 lbs |
| Temperature |
41 – 104 °F (5 – 40 °C) |
| Humidity |
10 – 90 % Non-Condensing |
| Operational Voltage |
110 – 240V | 50 – 60Hz | 15A |
| Cooling |
Air |
| Safety Class |
IV |
| Safety Features |
Emergency Stop Button | Key Control | Remote Interlock Connection | Reset | Emission Indicator |
| Mobile Connectivity |
Yes |
